owners manual Seat Altea
owners manual Seat Altea - year of production: 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015 - Seat Altea manuale del proprietario IT
Document: pdf (4.53 MB) 252 pages
all ratings: 0 average rating: 5
text version of content this owner's manual page from owners manual to the vehicle Seat Altea, year of production 2004 - 2015:
Dati tecnici
Motore diesel 2.0 TDI CR 103 kW (140 CV)
Dati del motore
Coppia motrice massima (Nm a
3
Potenza in kW (CV) a 1/min N. di cilindri/cilindrata (in cm ) Carburante
1/min)
Gasolio secondo la norma DIN EN 590,
103 (140)/4.200 320/1.750-2.500 4/1.968
a)
min. 51 CZ
a)
Numero Cetano (numero cetanico) = Misura che indica il grado di infiammabilità del gasolio.
ALTEA XL ALTEA FREETRACK
Prestazioni ALTEA ALTEA XL
Trazione integrale Trazione integrale
Velocità massima (km/h) 201 201 198 193
Accelerazione da 0 a 80 km/h (s) 6,6 6,7 6,9 6,9
Accelerazione da 0 a 100 km/h (s) 9,7 9,8 10,1 10,2
Peso (in kg)
Peso totale ammesso 1.985 2.034 2.132 2.159
Massa durante la marcia (con conducente) 1.465 1.490 1.588 1.615
Massa max. sull'asse anteriore 1.065 1.070 1.090 1.110
Massa max. sull'asse posteriore 955 1.020 1.080 1.070
Carico massimo consentito sul tetto 75 75 75 75
Carichi rimorchiabili (in kg)
Rimorchio senza freni 730 740 750 750
Rimorchio con freno in pendenze fino al 8% 1.500 1.500 1.650 1.650
Rimorchio con freno in pendenze fino al 12% 1.500 1.500 1.650 1.650
236
