text version of content this owner's manual page from owners manual to the vehicle Seat Ibiza, year of production 2002 - 2008:

220 If and when – Unscrew the screws F fig. 160 using a flat-blade screwdriver. Rear lights on frame A – Move the rear light outwards and pull. – If necessary, unplug the connector. – Unscrew the bolt G fig. 161. A – Take out the lamp holder. – Press and rotate the lamps to the left. – Remove faulty lamp and replace it. – Proceed in the reverse order, pressing gently on the outer edge Fig. 160 Rear lights on of the rear light (in the area of the metal clips). bodywork Note Make sure that when assembling all seals and rubbers are correctly fitted. Number plate light – Release transparent lamp cover by levering the tab with the flat part of a screwdriver. – Remove the defective lamp from the lamp holder, holding it in Fig. 161 Rear lights on the centre, press to one side and fit new lamp bodywork – Fit lamp cover in its space, taking special care when replacing the rubber seal and press until it clicks into place. Side light 2/ Brake light/ Indicator light – Open the tailgate.
