text version of content this owner's manual page from owners manual to the vehicle Mazda 5, year of production 2005 - 2010:

Body & Accessories Doors and Liftgate Sliding Door Open Lock Actuator • The sliding door open lock actuator holds the sliding door in the fully open position to prevent the door closing unexpectedly. • When the inner or outer sliding door handle is operated, a cable releases the open lock actuator, allowing the door to be closed. M5_09052 1 Lower roller bracket 4 Cable 2 Open lock actuator 5 Latch 3 Closing direction Service Training Mazda5 09-5
