212 Driving and operating
The camera is mounted in the tailgate
e.g. below the bumper or
handle and has a viewing angle of
underneath the vehicle, are not
130°.
displayed.
Do not reverse the vehicle by only
looking at the Info-Display and
check the surrounding area
behind and around the vehicle
before reversing.
Activation
Rear view camera is automatically
activated when reverse gear is
Trajectory lane of the vehicle is
engaged.
shown in accordance with the
steering angle.
Functionality
The function can be deactivated in the
Due to the high position of the camera
Settings menu in the Info-Display.
the rear bumper can be seen on the
Vehicle personalisation 3 134.
display as a guide to position.
The area displayed by the camera is
Warning symbols
limited. The distance of the image that
Warning symbols are indicated as
appears on the display differs from
triangles 9 on the picture which show
the actual distance.
obstacles detected by the rear
sensors of the advanced parking
Guiding lines
assist.
Dynamic guiding lines are horizontal
lines in one metre intervals projected
on the picture to define the distance
to shown objects.
