from owners manual to the vehicle Renault Scenic, year of production 2003 - 2009:
NU692_7_G5-FRA.qxd 22/10/04 11:50 Page 5.12
CHANGING A WHEEL: 5-seat Sc énic
Start screwing up jack 3 by hand at
4 first to align the base plate (which
2 should be inclined further inwards
thanthejackhead).Placeaplankof
woodunderthebaseplateif onsoft
ground.
1 Turn the wheelbrace to lift the
wheel off the ground.
Remove the bolts.
Remove the wheel.
Fit the emergency spare wheel on
the central hub and turn it to locate
the mounting holes in the wheel
3 and the hub.
Tightentheboltsandlowerthejack.
Loosenthenutsusingwheelbrace 1, With the wheels on the ground,
Park the vehicle on firm, located in the tool kit. Fit it so thattightentheboltsasmuch as
level ground which is not you press downwards rather than possible and get a RENAULT Dealer
slippery (e.g. avoid tiledpulling upwards. to check the tightness of the bolts as
flooring,etc.)-ifnecessary,Offer upjack 3horizontally, thejacksoon as possible (tightening torque
place a plank under the jack forhead should be positioned at the130 Nm).
support. Switch on the hazard levelofjackingpoint2 in the lower
warning lights. section of the bodywork closest to
With the parking brake applied, the wheel concerned, marked by an
engage a gear (first or reverse geararrow 4. If you have a puncture,
or position P for automatic replacethewheelassoon
gearboxes). as possible.
Ask all the passengers to leave the A tyre which has been
vehicle and keep them away from punctured should always be
the traffic. inspected(and repairedif
possible) by a specialist.
5.12
