text version of content this owner's manual page from owners manual to the vehicle KIA Carens, year of production 2006 - 2013:

IN CASE OF AN EMERGENCY Diesel engine DescriptionFuse ratingProtected componentRR DEF30A Rear Defroster INJECTOR 15A ECU DRL 10A DRL Unit (if equipped) INJ-DSL 20A ECU FOG LAMP 15A Fog Light ECU 10A Engine Control UnitTAIL 10A Tail Light (RR FOG) 10A Rear Fog Light (if equipped)ROOM/MEMORY15AAudio C/FAN 30A Cooling Fan Motor IG KEY1 30A Ignition Key 1 HAZARD 15A Hazard Switch (HLLD) 10A Head Light Leveling Device (if equipped) IG COIL 15A ECU HEAD(LOW) 15A Head Light Low BLOWER 30A Blower Motor HORN 15A Horn (S/WAMER) 20A Seat Warmer (if equipped)IG KEY230A Ignition Key 2 A/C-S/W 10A Mode ACT COND.FAN 20A Condenser Fan Motor (ABS) 30A ABS Unit (if equipped)F/FILTER30A Fuel Filter Heater (ABS) 25A ABS Unit (if equipped)RLY-COIL10A Seat Warmer P/WIN-RH 25A Power Window SW RH D/LOCK 20A Door Lock FUEL PUMP 10A Fuel Pump Unit BTN 30A Stop SW, Power Outlet HEAD 25A Head Light MAIN 140A Alternator A/CON 10A Magnetic Clutch HEATER3 40A Water Heater 3 (S/ROOF) 20A Sun Roof Unit (if equipped)GLOW60A Glow Plug P/WIN-LH 25A Power Window SW LH HEATER2 40A Water Heater 2 START 10A Start Relay HEATER1 40A Water Heater 1 HEAD(HI) 20A Head Light High 6-11
