SCHEIDINGSNET (2/2)
1 2
A 3
4 8
5
Aanbrengen van het Bevestiging aan de onderkant:
scheidingsnet A achter de – bevestig de haak 5 van de band van het
achterstoelen net aan de ring 8;
Aan beide kanten in de auto: – stel de band van het net zo af, dat het
Bevestiging aan de bovenkant: goed strak staat.
Verwijderen
– houd het klepje 2 omhoog met behulp
van een platte schroevendraaier of gelij-
kaardig om bij de bevestigingsopening te Maak de band los. Maak de gordels los.
komen,
– schuif de bovenste stang 1 van het net zo
ver mogelijk in het breedste deel 3 van de
opening,
Zorg ervoor dat het uiteinde
– schuif de stang in het onderste gedeel-
te 4 van de opening. van de stang 1 tegen het plaa-
twerk steunt en niet tegen het
plastic van het klepje.
3.37
