owners manual Volvo XC70

owners manual Volvo XC70 - year of production: 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007 - Volvo XC70 Cross Country 2007 owners manual EN

Document: pdf (10.49 MB) 283 pages

all ratings: 0 average rating: 5

text version of content this owner's manual page from owners manual to the vehicle Volvo XC70, year of production 1999 - 2007:

2007 Volvo XC70 Inflation pressure The tires are considered to be cold when they have the same temperature as the surrounding (ambient) air. This temperature is normally reached after the vehicle has been parked for at least 3 hours. After driving a distance of approximately 1 mile (1.6 km), the tires are considered to be hot. If you have to drive farther than this distance to pump your tire(s), check and record the tire pressure first and add the appropriate air pressure when you get to the pump. If checking tire pressure when the tire is hot, never "bleed" or reduce air pressure. The tires are hot from driving and it is normal for pressures to increase above recommended cold pressures. A hot tire at or below recommended cold inflation pressure could be significantly under-inflated. To check inflation pressure: - Remove the cap from the valve on one tire, then firmly press the tire gauge onto the valve. - Add air to reach the recommended air pressure. - Replace the valve cap. - Repeat this procedure for each tire, including the spare. - Visually inspect the tires to make sure there are no nails or other objects embedded that could puncture the tire and cause an air leak. - Check the sidewalls to make sure there are no gouges, cuts, bulges or other irregularities. NOTE: ● If you overfill the tire, release air by pushing on the metal stem in the center of the valve. Then recheck the pressure with your tire gauge. ● Some spare tires require higher inflation pressure than the other tires. Consult the tire inflation table on pages 160 and 161 or see the inflation pressure placard. pg. 160 Wheels and tires Tire inflation pressure tables - U.S. models The following tire pressures are recommended by Volvo for your vehicle. Refer to the tire inflation placard for information specific to the tires installed on your vehicle at the factory. Cold tire pressures up to five persons Tire size Front, psi (kPa) Rear, psi (kPa) file:///K|/ownersdocs/2007/2007_XC70/07xc70_07.htm (6 of 24)12/30/2006 5:51:40 PM
