text version of content this owner's manual page from owners manual to the vehicle Land Rover Discovery, year of production 1998 - 2004:

Wheel Changing Using the wheel chocks Operating the jack 1 A 2 BC H2510 3 Slot the two parts of the jack lever together, ensuring that the spring clip protrudes from the engagement slot where the two parts join (see inset ‘A’). Close the jack release valve by using the notched end of the jack lever to turn the valve fully clockwise (see inset ‘B’). Insert the H3098 lever into the socket as shown (inset ‘C’) and twist the lever to lock it into the socket. If possible, position the vehicle on level ground, Pump the lever up and down to raise the jack. chocking both sides of the wheel diagonally opposite the one to be removed. To lower the jack, detach the lever (twist and If jacking the vehicle on a slope is unavoidable, pull) and then slot the notched end over the place the chocks on the downhill side of the two pegs on the release valve. Slowly turn the opposite wheels. release valve anti-clockwise allowing the weight of the vehicle to lower the jack. The wheel chocks are stowed with the jack DO NOT fully unscrew the release valve. handle and wheel nut spanner in the tool bag. Assemble the wheel chocks as follows: 1. Pull the two halves of the chock apart. 2. Twist one half of the chock 180°. 3. Push the two halves back together. 179
