Seating and Safety Restraints
Howdoesthe Safety Canopy system work?
The design and development of the
Safety Canopy system included
recommended testing procedures
that were developed by a group of
automotive safety experts known as
the Side Airbag Technical Working
Group. These recommended testing
procedures help reduce the risk of
injuries related to the deployment of
side airbags (including the Safety
Canopy).
The Safety Canopy system consists
of the following:
• An inflatable nylon curtain with a
gas generator concealed behind
the headliner and above the doors
(one on each side of vehicle).
• A headliner designed to flex open
above the side doors to allow
Safety Canopy deployment.
• The same readiness airbag light, electronic control and diagnostic unit
as used for the front airbags.
• Two crash sensors mounted on the B pillar (one on each side of the
vehicle).
• Two crash sensors located at the C pillar behind the rear doors (one
on each side of the vehicle).
• Rollover sensor in the restraints control module (RCM).
The Safety Canopy system, in combination with safety belts, can help
reduce the risk of severe injuries in the event of a significant side impact
collision or rollover event.
Children 12 years old and under should always be properly restrained in
the second or third row seats. The Safety Canopy will not interfere with
children restrained using a properly installed child or booster seat
because it is designed to inflate downward from the headliner above the
doors along the side window opening.
The Safety Canopy system is designed to activate when the vehicle
sustains lateral deceleration sufficient to cause the side crash sensor to
160
2009 Edge (edg)
Owners Guide, 1st Printing
USA(fus)
