text version of content this owner's manual page from owners manual to the vehicle Mazda 5, year of production 2005 - 2010:

Front Suspension Suspension Front Shock Absorber • A shock absorber with an internal rebound spring is used to control wheel-lift* during hard cornering. The rebound spring allows a limited amount of movement of the shock absorber when it is fully extended. Without the spring the shock absorber would top-out, making the suspension ineffective and causing wheel hop or wheel lift. *Wheel-lift: Tendency for wheels on the inside of a curve to lift off the ground during cornering. M5_02001 1 Rebound spring 3 Gas chamber 2 Oil chamber 02-4 Service Training Mazda5
