BBEELLAANNGGRRIIJJKKSSTTEE OONNDDEERRDDEELLEENN EELLEEKKTTRRIISSCCHHEE AAUUTTOO
Belangrijkste onderdelen elektrische auto
Hoogspanningsbatterij Elektromotor: Gebruikt de
On-Board Charger elektrische energie die is
(OBC) opgeslagen in de
hoogspanningsbatterij om de auto
EPCU aan te drijven (werkt als een
(inverter + LDC) verbrandingsmotor in een
conventionele auto).
Reductieoverbrenging:Brengt
de rotatiekracht van de
elektromotor over op de wielen
met de juiste toerentallen en het
juiste koppel.
Elektro Hoogspanningsbatterij (lithium-
motor ion polymeer):Slaat elektrische
energie op en levert de voeding
Reductieov die de elektrische auto nodig heeft
erbrenging om te rijden (de 12V-accu verzorgt
de voeding van voertuigsystemen,
zoals de verlichting en de
OAEEQ016001 ruitenwissers).
❈OBC:On-Board Charger
On-Board Charger (OBC):Extern apparaat om de hoogspanningsbatterij
(langzaam) te laden. ❈LDC: DC-DC-
laagspanningsconverter
Inverter: Zet gelijkstroom om in wisselstroom voor de voeding van de
elektromotor en zet wisselstroom om in gelijkstroom om de
hoogspanningsbatterij te laden.
LDC: Zet de voedingsspanning van de hoogspanningsbatterij om in
laagspanning (12 V) voor de voeding van onderdelen in de auto (DC-DC).
